SAARA Cluster

SAARA Cluster is an upgrade for SAARA Standard. If you are new to our products, please choose from one of our options for getting to know our systems. We offer online demo which allows to get familiarized to our products.

SAARA Cluster is available for purchase to be installed at your premises. It comes with free remote installation service. Any bugfix and security updates are free during the lifetime of the product, and free product updates during warranty period. You can also opt for support during after-warranty period. On-site training and 24/7 support available as options.

Click "Request Quote" button to inquire about all available options.

For those interested on our Cloud based SAARA product (formerly dtlvoip.com), please Sign Up for 14 days free demo using the link on the top menu bar. You can also use demo in case you would like to explore product before deciding to purchase or rent it.

SAARA Cluster

Carrier grade highly redundant and scalable VoIP system for high demand usage

With scalability and redundancy in mind, we have build our flagship product, SAARA Cluster for those customers looking to increase their system's capacity and reliability. Multi-server architecture, with scalable nodes and extensible modules, it is possible to grow the system to a very large scale. It is an upgrade path for users of SAARA Standard.
Product information
Help icon

SAARA Cluster (formerly known as LongBowBilling) is a high quality prepaid/post paid Billing and Accounting system for VoIP, TDM and Mobile Telephony services. Including it's switching component (formerly ArrowSwitch), a SIP/H.323 switch, it makes a complete VoIP system that can be utilized to offer variety of services, including:

  • Medium to large telephony operators offering alternative telecom services
  • MVNOs
  • Callshop chain operators
  • Call Termination service providers
  • Wholesale traffic agents and brokers
  • PC-to-phone, IP phone device services
  • and many more.

  • - Multiple Server
  • - Scalable and redundant
  • - For larger operations
  • - Install on premises
  • - All modules included
  • - Remote installation service
SAARA (Switching Authentication Authorization Routing and Accounting) Cluster package features a complete VoIP system for medium to large VoIP operations, like Callshops, PC to phone, Callback and others.

Scalability and Redundancy

  • Scalable to multiple servers, including several SIP servers, database servers, AAA servers, webservers, routing servers
  • Each module can be duplicated for redundancy
Features included but not limited to:

General Switch and Billing Features

  • Prepaid/postpaid multilevel Reseller, whitelabel branding billing
  • Based on LINUX or FreeBSD platform
  • SIP proxy and Registrar for retail and wholesale
  • H.323 gatekeeper for wholesale
  • Codec trans-coding: G.729a, G.723, G.711, GSM, iLBC, Speex
  • Multiple Reseller levels
  • Web based access for all levels, including enduser
  • Unlimited number of accounts, PINs, rate tables
  • Unlimited number of Carriers
  • Callshop operators interface
  • End users access interface
  • Wholesale carriers/partners interface
  • DID number support
  • IVR for calling card support
  • ANI (DID) based callback
  • Web based callback (web page button)
  • SMS callback
  • Active Calls display
  • System activity Reports, troubleshooting tools

Retail Account Management

  • Account authentication by username/password, ANI (calling number) or IP address
  • Assignment of reseller
  • Preset initial credit and currency
  • Different Account expiration types (fixed date or fixed number of days after first use)
  • Assign multiple rate tables (via product mapping)
  • Assign one or multiple Recurring services, e.g. monthly or other fees (via product mapping)
  • Assign multiple sub-accounts (aliases)
  • Location profile to ensure shortened dialing within country
  • Setting of IVR language and IVR options
  • Extensive Account info page (address, contacts, email, etc)

Wholesale Account (Carrier) Management

  • Authenticaion by IP address or IP address range (subnet) or IP + prefix
  • Multiple accounts per Carrier
  • Option to register with remote SIP Carrier (multiple registrations simultaneously)
  • Registration status report
  • Web access username and password of Carrier
  • Multicurrency

Batch PIN Management

  • Calling Card PIN Generation
  • PIN activation /de-activation (single and batch)
  • Different PIN length, prefix (initial digits), optional password for PIN
  • Manual or bulk recharge of PIN or batch of PINs
  • PIN upload from text file

Reporting

  • Payment history report
  • Invoices and corresponding CDR reports
  • Reports on Payments received during a period
  • ASR / ACD reports: total, by carrier, IP (hourly, daily)
  • Call Disconnect Cause Reports
  • Real time balance reporting

Rating and Billing Management

  • Unlimited rate tables in the system with ability to universally assign them to End user (PIN, ANI, etc), Carrier account (terminating / originating) or Reseller
  • Allow to add DNIS-based surcharges to any rate table, based on: dialed destination number and dialed access number
  • Create/edit/upload/copy/delete rate tables
  • Multiple rate tables per account or reseller via dialed prefix
  • Replace rate tables with new by specifying effective start time of particular table
  • Rate tables properties:
    • rates based on Country code, City code, longest digit match
    • multiple currencies, individually set per destination
    • rate per call duration time (rate per minute)
    • rate per call connect (rate per call)
    • variable call duration increment
    • free non-chargeable duration (grace time)
    • round-up short duration calls to specific duration
    • variable number of seconds in minute for IVR purposes
    • enable/disable particular destination or destination block
    • rates based on day or week or time of day
    • minimum and maximum number of digits in destination number
  • DNIS-based Rate surcharge properties:
    • surcharge based on dialed access number and destination number prefix
    • rate per minute surcharge
    • rate per call surcharge
    • surcharge currency
    • IVR language based on Access number dialed
  • Recurring services properties:
    • activate based on usage start criteria (account created / account in use)
    • Service run number of cycles or until stop criteria is met
    • Stop criteria: account disabled, account no balance
    • Services run periods: daily, weekly, monthly, bi-monthly

Routing Management

  • Unlimited number of Routing groups
  • Routing Group can hold unlimited number of Routes
  • Multi-level failover routing
  • Round robin routing for equal priority destinations
  • Percentage distributed routing based on Terminating Account capacity
  • Huntstop on any route
  • Manipulate the DNIS of a called number and pre-pend a technical prefix for advanced routing
  • Least Cost Routing
  • Upload Routing tables from text file

Calling Card and IVR Management

  • PIN based and PINless (ANI) based calling card support
  • Automatic ANI registration
  • Muliple language and currency support
  • Dial-in number to inquiry the balance of account
  • Balance announce, remaining time and call rate announce

Callback Management

  • ANI based callback, with the all features of calling cards
  • SMS callback via 3rd party gateway
  • Web callback from endusers interface

Enduser Selfprovision Interface

  • Signup via web interface, with various access options
  • Controllable rate plans and initial credits
  • Call detail, call summary, invoice and payments reports
  • Multiple payments methods: recharge voucher, Paypal, authorize.net, Moneybookers, Barclaycard, Ogone
  • PDF invoices
  • Speed-dial number directory (10 entries)
  • Web-callback (with pre-defined numbers)

Call shop Interface

  • Call Shop Web Interface with admin and operator level functions
  • Dynamically view status of the lines, including line status (idle, disabled, call connecting, active, finished) call duration counters, amount counters)
  • Display list of dialed numbers by current customer
  • Ability to accumulate calls within one invoice for same customer
  • Enter payment and clear the balance of current customer
  • Block / unblock any line
  • Reports
  • Optional module to connect LCD call informational displays in booths(cabins)
Host OS Linux
Accounts unlimited
Max Resellers unlimited
Reseller levels 5
Callshops Yes
Routing Yes
Max Carriers unlimited
Max Callshops unlimited
Protocols SIP, H.323
AAA Protocol RADIUS
